Table of contents

1. Our Speaker Today

2. Context And Prerequisites

3. The Regression Testing Problem

4. Agile-ish Toolbox Solution

5. Future Work

6. Q&A

Context Awareness

What is imperative to understand in our environment:

Scripted tests are only half of the Testing story

White box testing is not scary

... or hard!

Version Control Systems are powerful

... and vital tool!

Regression testing is painful

But essential, because software changes constantly

Team Structure Impacts Regression Testing

Agile requires that the whole team should take responsibility for regression testing

... and not only testers!

Releases increment the functionality

The development time does not necessarily grow with releases,

... but the testing time does!

Within the same budget

No company will invest more time in testing and less for development

... we need scalable solution!

Solution Stack Overview

RCRCRC mnemonic

Code indexer, search and navigation tool - Starscope

Git VCS

Regression testing is change-focused

How much effort is required, ultimately depends upon the scope.

Which can be effectively decided when the tester gets input from the business and dev team about the

Amount

Scope

and Nature of change!

Amount of change

# here be dragons
# diff between two tags
cd ./to/git/repo
git checkout {main-branch} # (e.g. master)
git fetch --all
git tag --list
git diff {tag1} {tag2} --stat
git diff {tag1} {tag2} -- some-file-name
git diff --name-only {tag1} {tag2}


Abstruse CI platform example #1

user@~/Desktop/abstruse (master): git diff v1.5.0 v1.6.6 --stat
# files omitted for readability
angular.json                                                               |   140 +
package-lock.json                                                          | 20390 ++++++++++++++++++++++++++++++++++++++++++-----------------------------------------------
package.json                                                               |   249 +-
src/api/config.ts                                                          |    32 +-
src/api/db/migrations.ts                                                   |     7 +-
src/api/db/repository.ts                                                   |   107 +-
src/api/deploy/aws-code-deploy.ts                                          |    50 +-
src/api/deploy/aws-elastic.ts                                              |    50 +-
src/api/deploy/aws-s3.ts                                                   |   220 +-
src/api/env-variables.ts                                                   |     4 +-
src/api/security.ts                                                        |    17 +-
src/api/server-routes.ts                                                   |   253 +-
# files omitted for readability



Scope of change

# can be found via tools that can peek changed functions’ references in the code
gem install starscope # install the code indexer tool
tsc src/**/*.ts --outDir js/ # compile Typescript to JS
starscope js/ # create local DB
starscope -q calls,{function-name-all-references}
starscope -q requires,{function-name} | grep -F 'file/location'


Abstruse CI platform example #2

# file level
user@~/Desktop/abstruse (master): tsc src/**/*.ts --outDir js/
user@~/Desktop/abstruse (master): starscope js/
user@~/Desktop/abstruse (master): starscope -q requires,process-manager
./process-manager -- js/api/socket.js:11 (var process_manager_1 = require("./process-manager");)
./process-manager -- js/api/webhooks.js:7 (var process_manager_1 = require("./process-manager");)
./process-manager -- js/api/server-routes.js:27 (var process_manager_1 = require("./process-manager");)
./process-manager -- js/api/docker-stats.js:7 (var process_manager_1 = require("./process-manager");)

# method_level
# src/api/process-manager.ts:export function restartJob(jobId: number)
user@~/Desktop/abstruse (master): starscope -q calls,restartJob
restartJob -- js/api/socket.js:210 (process_manager_1.restartJob(parseInt(event.data.jobId, 10)))


Nature of change

Can be best found in direct communication with the dev team.

It is a composite index of Coupling (Scope of change) and Type Rank.

Usually the following types of files are with high level of feature dependencies:

• Configurations e.g. dependencies, environment variables

• Wrappers e.g. Decorators, Proxy, Bridge, Facade, Adapter

• Base classes

• Abstractions e.g. in Typescript look for keywords like abstract, extends

Abstruse CI platform example #3

user@~/Desktop/abstruse (master): git diff v1.5.0 v1.6.6 --stat
...
src/app/components/app-header/app-header.component.ts                      |     7 +-
...

user@~/Desktop/abstruse (master): grep -rnw 'js/' -e 'decorator'
...
js//src/app/components/app-header/app-header.component.js:11:var __param = (this && this.__param) || function (paramIndex, decorator) {
...


RCRCRC

Regression Testing Heuristic by Karen N. Johnson

Recent

Core

Risk

Configuration

Repaired

Chronic

Recent and Repaired

New features, new areas of code are more vulnerable.

Bug fixes can introduce new issues.

# diff between two tags
cd ./to/git/repo
git checkout {main-branch} # (e.g. master)
git fetch --all
git log -{number-of-commits-back} --oneline
git diff {SHA1} {SHA2} --stat
git diff {SHA1} {SHA2} -- some-file-name
git diff --name-only {SHA1} {SHA2}


Abstruse CI platform example #4

user@~/Desktop/abstruse (master): git diff v1.5.0 v1.6.6 -- src/api/security.ts
...
-import * as crypto from 'crypto';
...
-import { RSA } from 'rsa-compat';
+import { RSA } from 'rsa-compat-ssl';
...
+import * as bcrypt from 'bcrypt';

 export function generatePassword(plain: string):
-  return new Promise((resolve, reject) => {
-    resolve(calculateMd5(plain));
-  });
+  return bcrypt.hash(plain, 12);
 }


Abstruse CI platform example #5

 export function comparePassword(plain: string, hash: string): Promise {
-  return generatePassword(plain)
-    .then(calculated => hash === calculated);
+  return bcrypt.compare(plain, hash);
 }

 export function generateJwt(data: any): Promise {
   return new Promise((resolve, reject) => {
+    delete data.password;
+
     jwt.sign(data, config.jwtSecret, {}, (err: jwt.JsonWebTokenError, token: string) => {
       if (err) {
         reject(err);
@@ -42,10 +41,6 @@ export function decodeJwt(token: string): any {
   }
 }

-export function calculateMd5(str: string): string {
-  return crypto.createHash('md5').update(str).digest('hex');
-}
-


Configuration sensitive

Code that’s dependent on environment settings can be vulnerable.

for i in $(find . -name '*config*')
do
     git diff {tag1} {tag2} --stat $i
done


Abstruse CI platform example #6

user@~/Desktop/abstruse (master): ll
# files omitted for readability
total 1384
-rw-r--r--   1 evgenikostadinov  staff   458B Apr  2 13:47 .abstruse.yml
-rw-r--r--   1 evgenikostadinov  staff   2.2K Apr  2 13:47 Dockerfile
-rw-r--r--   1 evgenikostadinov  staff   3.7K Apr  2 13:47 angular.json
-rw-r--r--   1 evgenikostadinov  staff   877B Apr  2 13:47 karma.conf.js
-rw-r--r--   1 evgenikostadinov  staff   510K Apr  2 13:47 package-lock.json
-rw-r--r--   1 evgenikostadinov  staff   4.1K Apr  2 13:47 package.json
-rw-r--r--   1 evgenikostadinov  staff   536B Apr  2 13:47 protractor.conf.js
-rw-r--r--   1 evgenikostadinov  staff   363B Apr  2 13:47 tsconfig.json
-rw-r--r--   1 evgenikostadinov  staff   1.2K Apr  2 13:47 webpack.api.js


Abstruse CI platform example #7

user@~/Desktop/abstruse (master): for i in $(find . -name '*config*');do git diff v1.5.0 v1.6.6 --stat $i; done
 .editorconfig | 13 +++++++++++++
 1 file changed, 13 insertions(+)
 tsconfig.json | 32 ++++++++++++++------------------
 1 file changed, 14 insertions(+), 18 deletions(-)
 e2e/tsconfig.e2e.json | 12 ++++++++++++
 1 file changed, 12 insertions(+)
 src/tsconfig.api.json | 30 ++++++++++++++++++++++++++++++
 1 file changed, 30 insertions(+)
 src/app/services/config.service.ts | 8 ++++----
 1 file changed, 4 insertions(+), 4 deletions(-)
 src/tsconfig.app.json | 15 +++++++++++++++
 1 file changed, 15 insertions(+)
 src/api/config.ts | 32 ++++++++++++++++++++++----------
 1 file changed, 22 insertions(+), 10 deletions(-)
 src/tsconfig.spec.json | 25 +++++++++++++++++++++++++
 1 file changed, 25 insertions(+)


Chronic

Hottest files via log crunching (would be great to compare with Defect density heatmap).

git log --name-status $*|  grep -E '^[A-Z]\s+'|  cut -c3-500|  sort|  uniq -c|  grep -vE '^ {6}1 '| sort -n|  tail


Abstruse CI platform example #8

user@~/Desktop/abstruse (master): git log --name-status $* | grep -E '^[A-Z]\s+' | cut -c3-500 | sort | uniq -c | grep -vE '^ {6}1 ' | sort -n | tail
# files omitted for readability
 71 src/api/socket.ts
 84 src/api/server-routes.ts
 90 src/api/process.ts
 137 src/api/process-manager.ts
